The sturdy VARIANT T1 Overlap is distinguished by its outstanding top speed of up to 18 m/min. Combined with a slim, compact design, it allows a perfect view into the weld seam from all sides.
This tool’s top welding speed of up to 18 m/min and its slim, compact design make it a winning choice.
VARIANT T1 – 230 V / 3680 W / 20 mm nozzle / EU-plug
| ttribute | Unit | Value |
|---|---|---|
| Voltage | V~ | 230 |
| Power | W | 3680 |
| Weld seam width | mm | 20 |
| Temperature | °C | 100 -620 |
| Air flow range | % | 40 – 100 |
| Speed | m/min | 1.5 – 18 |
| Size (L × B × H) | mm | 500 × 400 × 195 |
| Weight | kg | 22 |
| Conformity mark |  |
|
| Approval mark |  |
|
| Protection class I |  |
VARIANT T1 – 230 V / 3680 W / 40 mm nozzle / EU-plug
| Attribute | Unit | Value |
|---|---|---|
| Voltage | V~ | 230 |
| Power | W | 3680 |
| Weld seam width | mm | 40 |
| Temperature | °C | 100 -620 |
| Air flow range | % | 40 – 100 |
| Speed | m/min | 1.5 – 18 |
| Size (L × B × H) | mm | 500 × 400 × 195 |
| Weight | kg | 22 |
| Conformity mark | |
|
| Approval mark | |
|
| Protection class I | |
VARIANT T1 – 400 V / 5700 W / 20 mm nozzle / CEE-plug (3LNPE)
| Attribute | Unit | Value |
|---|---|---|
| Voltage | V~ | 400 |
| Power | W | 5700 |
| Weld seam width | mm | 20 |
| Temperature | °C | 100 -620 |
| Air flow range | % | 40 – 100 |
| Speed | m/min | 1.5 – 18 |
| Size (L × B × H) | mm | 500 × 400 × 195 |
| Weight | kg | 22 |
| Conformity mark | |
|
| Approval mark | |
|
| Protection class I | |
VARIANT T1 – 400 V / 5700 W / 40 mm nozzle / CEE-plug (3LNPE)
| Attribute | Unit | Value |
|---|---|---|
| Voltage | V~ | 400 |
| Power | W | 5700 |
| Weld seam width | mm | 40 |
| Temperature | °C | 100 -620 |
| Air flow range | % | 40 – 100 |
| Speed | m/min | 1.5 – 18 |
| Size (L × B × H) | mm | 500 × 400 × 195 |
| Weight | kg | 22 |
| Conformity mark | |
|
| Approval mark | |
|
| Protection class I | |
General Catalogs :
GC – General Catalog Plastic Welding (12,92 MB)
BR – Accessories Hot air Hand Tools (3,63 MB)
Manuals :
QG – VARIANT T1 (0,64 MB)
Safety instructions – Automatic Welders / Extrusion Welders / Welding Machines (33,26 MB)
BA – VARIANT T1 Overlap (38,69 MB)
BA – VARIANT T1 (33,60 MB)
Leister VARIANT T1 welds billboards and tarpaulins easily
