Electronically controlled efficient hot air welding of industrial fabrics with the UNIPLAN E.
The small, lightweight and handy hot-air welder produces perfect welding results. UNIPLAN E is electronically controlled for reproducible results.
UNIPLAN E 20 mm – 230V / 2300 W / EU-plug
| Attribute | Unit | Value |
|---|---|---|
| Voltage | V~ | 230 |
| Power | W | 2300 |
| Weld seam width | mm | 20 |
| Temperature | °C | 80 – 620 |
| Air flow range | % | 50 – 100 |
| Speed | m/min | 1.0 – 7.5 |
| Size (L × B × H) | mm | 420 × 270 × 210 |
| Weight | kg | 11.5 |
| Conformity mark |  |
|
| Approval mark |  |
|
| Protection class I |  |
UNIPLAN E 30 mm – 230V / 2300 W / EU-plug
| Attribute | Unit | Value |
|---|---|---|
| Voltage | V~ | 230 |
| Power | W | 2300 |
| Weld seam width | mm | 30 |
| Temperature | °C | 80 – 620 |
| Air flow range | % | 50 – 100 |
| Speed | m/min | 1.0 – 7.5 |
| Size (L × B × H) | mm | 420 × 270 × 210 |
| Weight | kg | 11.5 |
| Conformity mark | |
|
| Approval mark | |
|
| Protection class I | |
General Catalogs :
GC – General Catalog Plastic Welding US Version (12,97 MB)
BR – Accessories Hot air Hand Tools (3,62 MB)
Manuals :
BA – UNIPLAN-E (3,24 MB)
