Smallest air heater with integrated temperature probe. For heat application concentrated to a point.
The world’s smallest air heater with an integrated temperature probe. Especially suited for applications in which heat is concentrated to a point. It is simple to incorporate into the tightest spaces. Leister’s LE MINI operates with compressed air at a pressure of 200 kPa (29 psi). Model versions are available with or without an integrated sensor.
LE MINI SENSOR – 230 V / 800 W
| Attribute | Unit | Value |
|---|---|---|
| Voltage | V~ | 230 |
| Power | W | 800 |
| Max. air outlet temperature | °C – 800 W | 750 |
| Min. air volume | l/min – 800 W | 10 |
| Weight LE MINI | kg – 800 W | 0.15 |
| Size (L x ∅) | mm | 308 × 25 |
| Max. air inlet temperature | °C | 60 |
| Max. ambient temperature | °C | 60 |
| Max. supply air pressure | kPa | 200 |
| Weight Converter | kg | 0.19 |
| Conformity mark |  |
|
| Approval mark |  |
|
| Protection class II |  |
LE MINI SENSOR – 230 V / 400 W
| Attribute | Unit | Value |
|---|---|---|
| Voltage | V~ | 230 |
| Power | W | 400 |
| Max. air outlet temperature | °C – 400 W | 600 |
| Min. air volume | l/min – 400 W | 10 |
| Weight LE MINI | kg – 400 W | 0.12 |
| Max. air inlet temperature | °C | 60 |
| Max. ambient temperature | °C | 60 |
| Max. supply air pressure | kPa | 200 |
| Weight Converter | kg | 0.19 |
| Size (L x ∅) | mm | 200 × 25 |
| Conformity mark | |
|
| Approval mark | |
|
| Protection class II | |
LE MINI SENSOR – 120 V / 400 W
| Attribute | Unit | Value |
|---|---|---|
| Voltage | V~ | 120 |
| Power | W | 400 |
| Max. air outlet temperature | °C – 400 W | 600 |
| Min. air volume | l/min – 400 W | 10 |
| Weight LE MINI | kg – 400 W | 0.12 |
| Max. air inlet temperature | °C | 60 |
| Max. ambient temperature | °C | 60 |
| Max. supply air pressure | kPa | 200 |
| Weight Converter | kg | 0.19 |
| Size (L x ∅) | mm | 200 × 25 |
| Conformity mark | |
|
| Approval mark | |
|
| Protection class II | |
