GEO & Civil EngineeringPlastic Welding Application

COMET

The small powerhouse, COMET, is specially designed for the demands of landfill sites, mines and tunnels.

หมวดหมู่: , , ป้ายกำกับ:
  • Lightweight and compact
  • Digital display of temperature and velocity
  • Closed-loop control of temperature and drive
  • Easy and user-friendly

This compact, heavy-duty welding machine is in use worldwide. The small powerhouse is specially designed for the demands of landfill sites, mines and tunnels.

Technical Data

COMET – wedge 50 mm / PE / 230 V / 1200 W / EU-plug

Attribute Unit Value
Power W 1200
Voltage V~ 230
Max overlap mm 125
Temperature °C 80 – 420
Speed m/min 0.8 – 3.2
Welding pressure N 100 – 1000
Weld seam mm 2 × 15
Material thickness mm 0.5 – 3
Size (L × B × H) mm 295 × 250 × 245
Weight kg 7.5
Conformity mark CE Certification
Protection class I Protection Class I

COMET – wedge 50 mm / PE / 120 V / 1200 W / EU-plug

Attribute Unit Value
Voltage V~ 120
Power W 1200
Max overlap mm 125
Temperature °C 80 – 420
Speed m/min 0.8 – 3.2
Welding pressure N 100 – 1000
Weld seam mm 2 × 15
Material thickness mm 0.5 – 3
Size (L × B × H) mm 295 × 250 × 245
Weight kg 7.5
Conformity mark CE Certification
Protection class I Protection Class I

COMET – wedge 50 mm / PVC / 230 V / 1200 W / EU-plug

Attribute Unit Value
Power W 1200
Voltage V~ 230
Max overlap mm 125
Temperature °C 80 – 420
Speed m/min 0.8 – 3.2
Welding pressure N 100 – 1000
Weld seam mm 2 × 15
Material thickness mm 0.5 – 3
Size (L × B × H) mm 295 × 250 × 245
Weight kg 7.5
Conformity mark CE Certification
Protection class I Protection Class I

COMET – wedge 70 mm / PE / 230 V / 1500 W / EU-plug

Attribute Unit Value
Power W 1500
Voltage V~ 230
Max overlap mm 125
Temperature °C 80 – 420
Speed m/min 0.8 – 3.2
Welding pressure N 100 – 1000
Weld seam mm 2 × 15
Material thickness mm 0.5 – 3
Size (L × B × H) mm 295 × 250 × 245
Weight kg 7.5
Conformity mark CE Certification
Protection class I Protection Class I

COMET – wedge 70 mm / PE / 120 V / 1500 W / EU-plug

Attribute Unit Value
Voltage V~ 120
Power W 1500
Max overlap mm 125
Temperature °C 80 – 420
Speed m/min 0.8 – 3.2
Welding pressure N 100 – 1000
Weld seam mm 2 × 15
Material thickness mm 0.5 – 3
Size (L × B × H) mm 295 × 250 × 245
Weight kg 7.5
Conformity mark CE Certification
Protection class I Protection Class I

COMET – wedge 95 mm / PE / 230 V / 1850 W / EU-plug

Attribute Unit Value
Power W 1850
Voltage V~ 230
Max overlap mm 125
Temperature °C 80 – 420
Speed m/min 0.8 – 3.2
Welding pressure N 100 – 1000
Weld seam mm 2 × 15
Material thickness mm 0.5 – 3
Size (L × B × H) mm 295 × 250 × 245
Weight kg 7.5
Conformity mark CE Certification
Protection class I Protection Class I



Downloads

General Catalogs :
GC – General Catalog Plastic Welding (12,92 MB)
BR – Accessories Hot air Hand Tools (3,63 MB)

Manuals :
BA – COMET

VDO

Leister COMET hot-wedge welding
