The new IGNITER ignition blower from Leister has been specially developed for installation into pellet and wood chip boilers. The IGNITER BR4 with 3.4 kW has what it takes. The interface was selected so that the ignition blowers can easily be installed into any heating boiler.
IGNITER BR4
Specially developed for installation in pellet and wood chip heating systems. Up to 3400 W performance.
Technical Data
IGNITER BR4 – 230 V / 3400 W / 50 Hz
| Attribute | Unit | Value |
|---|---|---|
| Voltage | V~ | 230 |
| Frequency | Hz | 50 |
| Power | W | 3400 |
| Min. air volume (20°C) | l/min | 230 |
| Air pressure | kPa | 2.48 |
| Max. air outlet temperature | °C | 600 |
| Noise emission level | dB(A) | 68 |
| Aperture ∅ | mm | 90 |
| Weight | kg | 1.2 |
| Length | mm | 294 |
| Conformity mark |  |
|
| Approval mark |  |
|
| Protection class II |  |
Downloads
General Catalogs :
GC – General Catalog Process Heat (7,95 MB)
Brochures :
BR – Hot-air blowers (1,28 MB)
BR – Process Heat – useful formulas (0,05 MB)
Manuals :
BA – IGNITER (5,15 MB)
